UNI-T UT61A UT61B UT61C UT61D UT61E Digital Multimeter true rms AC DC Meter Software CD & Data Hold Multitester+Gift

RMS digital multimeter

By UNI-T

Features and specifications:

Buy 1 Multimeter and get 1 Pouch bag for free!

UT61 series introduction:
Digital multimeter model UT61A, UT61B, UT61C, UT61D (True RMS) and UT61E (True RMS) is an auto-ranging multimeter. The enclosure structure design adopts an advanced ?co-injection? technique in order to provide sufficient insulation. The meter can measure AC/DC voltage and current resistance, diode, continuity buzzer, capacitance, frequency, temperature (C or F), hFE, and EF function.

Main Features:
1. UT61A/B/C/D/E are True RMS measurements
2. All models have analogue bar graph
3. Duty Cycle up to 0.1%-99.9%
4. Auto range and Auto power off
4. With a RS-232 connect with computer to record data?Except UT61A?
5. Data hold and MAX/MIX measurement
6. Input impedance for DCV
7. LCD back-light display(Except UT61E)
8. 22000 count display for UT61E,6000 count display for UT61C&D,4000 count display for UT61A&B
9. With Weak signals measurement
10. Continuity Buzzer alarming
11. Temperature measurement range -40 ?C ? 1000?C/-40?F?1832?F(Only UT61B&UT61C)

Parameters:
DC Voltage for UT61A:400mV/4V/40V/400V/1000V
DC Voltage for UT61B:40mV/400mV/4V/40V/400V/1000V
DC Voltage for UT61C&UT61D:60mV/600mV/6V/60V/600V/1000V
DC Voltage for UT61E:220mV/2.2V/22V/220V/1000V

AC Voltage for UT61A:400mV/4V/40V/400V/750V
AC Voltage for UT61B:40mV/400mV/4V/40V/400V/750V
AC Voltage for UT61C&UT61D:60mV/600mV/6V/60V/600V/750V
AC Voltage for UT61E:220mV/2.2V/22V/220V/750V

DC Current for UT61A&UT61B:400?A/4000?A/40mA/400mA/4A/10A
DC Current for UT61C&UT61D:600?A/6000?A/60mA/600mA/6A/10A
DC Current for UT61E:200?A/2200?A/22mA/220mA/2.2A/10A

AC Current for UT61A&UT61B:400?A/4000?A/40mA/400mA/4A/10A
AC Current for UT61C&UT61D:600?A/6000?A/60mA/600mA/6A/10A
AC Current for UT61E:200?A/2200?A/22mA/220mA/2.2A/10A

Resistance for UT61A&UT61B:400?/4k?/40k?/400k?/4M?/40M?
Resistance for UT61C&UT61D:600?/6k?/60k?/600k?/6M?/60M?
Resistance for UT61E:220?/2.2k?/22k?/220k?/2.2M?/22M?/220M?

Capacitance for UT61A&UT61B:40nF/400nF/4?F/40?F/400?F/4000?F
Capacitance for UT61C&UT61D:40nF/400nF/4?F/40?F/400?F/4000?F
Capacitance for UT61E:22nF/220nF/2.2?F/22?F/220?F/2.2mF/22mF/220mF

Frequency for UT61A&UT61B:10Hz-10MHz
Frequency for UT61C&UT61D:10Hz-10MHz
Frequency for UT61E:10Hz-220MHz

Packages includes:
? 1 x UNI-T digital multimeter UT61A/B/C/D/E
? 1 x Test leads
? 1 x RS-232C interface cable (Except UT61A)
? 1 x Point contact K type temperature Probe (UT61B and UT61C Only)
? 1 x UT61 Multi-purpose socket
? 1 x English manual
? 1 x Software CD
? 1 x Black bag
? 1 x Color box

Showcase

UNI-T UT61 series digital multimeter

Panel details

1) LCD display
2) Hold function
3) Functional button
4) Relative measuring key
5) Peak value measurement
6) Yellow button
7) Blue button
8) Rotary switch
9) Input terminal
10) Measuring mAuA?C input
11) Measuring V ? HZ diode input
12) COM measurement input
