Mitutoyo 103-147-10 Outside Micrometer

Description

103-147-10 Outside Micrometer – with Ratchet Stop: 250-275mm

The Mitutoyo 103-147-10 Micrometer has the following specifications:
● Range: 250-275mm
● Graduation: 0.01mm
● Accuracy: +/- 5um
● Mass(g): 1405

Features:
● Hammertone-green, baked-enamelfinished frame.
● Ratchet Stop or Friction Thimble for exact repetitive readings.
● With a standard bar except for 0-25mm model.

Technical Data
● Graduation: 0.01mm, 0.001mm
● Flatness: 0.6µm for models up to 300mm; 1Ìm for models over 300mm
● Parallelism: (2+R/100)µm, R=max. range (mm)
● Measuring faces: Carbide tipped
Note: Models with a range up to 1000mm are available
