Mitutoyo 103-146-10 Outside Micrometer

Description

103-146-10 Outside Micrometer – with Ratchet Stop: 225-250mm

The Mitutoyo 103-146-10 Micrometer has the following specifications:
    Range: 200-225mm
    Graduation: 0.01mm
    Accuracy: +/- 5um
    Mass(g): 1255

Features:
    Hammertone-green, baked-enamelfinished frame.
    Ratchet Stop or Friction Thimble for exact repetitive readings.
    With a standard bar except for 0-25mm model.

Technical Data
    Graduation: 0.01mm, 0.001mm
    Flatness: 0.6µm for models up to 300mm; 1Ìm for models over 300mm
    Parallelism: (2+R/100)µm, R=max. range (mm)
    Measuring faces: Carbide tipped
    Note: Models with a range up to 1000mm are available
