Mega CRP20 Hydraulic Folding Crane 2TON
NOMINAL FORCE
2000 Kg
CHARACTERISTICS
All models are fitted with polyamide wheels and castors to facilitate maneuverability. These wheels will not damage garage floors, do not rust, and are quiet in operation.
The extendable jib, swivel castors, and hook with latch allow easy access to the load and are very maneuverable.
The extendable jib change position at the pushing of a button. It has a handle and a window to show jib position.
The parallel legs version grants extra functionality.
A foot pedal facilities the in-shop handling of the crane.
Rubber protections to prevent any possible damage to the vehicle or to the crane legs. They improve visibility to prevent accidental bumping.
The new positioning of the swivel wheels allows for excellent maneuverability. Patented.
SECURITY
- LCS lowering control system
- Operation by the “dead man’s” principle (the operation is halted if the user accidentally loses control)
- Safety Overload Valve
- Hydraulic stroke limitation
TECHNICAL SHEET
| Capacity (kg) | A | B | C | D | E | R min | R max | F | G | H | Weight (kg) | Reference |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2000 | 1740 | 2460 | 1800 | 1070 | 170 | 1200 | 1610 | 740 | 300 | 1050 | 150 | CRP20 |
