GIACOMINI A61 Test and Drain Valve – DB-A61Y006-G

AGF Test and Drain Valve, Threaded ends, Model 1000

The AGF Manufacturing Inc. Model 1000 TESTanDRaIn? provides both the test function and the express drain function for a wet fire sprinkler system.

The Model 1000 complies with the requirements of NFPA-13, NFPA-13R, and NFPA-13D. The Model 1000 TESTanDRaIn? is a compact single handle ball valve which includes a tamper resistant test orifice and integral tamper resistant sight glasses, and is 300 PSI rated.

Features

Available in a full range of sizes from 3/4″ to 2″ NPT and BSPT, with all specifiable orifice sizes 3/8″ , 7/16″, 1/2″ , 17/32″ , 5/8″, 3/4″, and K25 as required by NFPA 13, 2007 Edition (see reverse).
The orifice size is noted on the indicator plate and the valve features a tapped and plugged port for system access.
A locking kit is available and can be ordered with the valve to provide vandal resistance or prevent unintentional alarm activation.
Repair kits including (1) adapter gasket, (1) ball, (2) valve seats, (1) stem packing, and (1) stem washer are available for all TESTanDRaIn? valves.

*Valve and orifice size must be specified when ordering.

*Orifice Size Available: 3?8″, 7?16″, 1?2″, 17?32″, ELO (5?8″)*, ESFR (3?4″)*, & K25**
