Extech 380396: High Voltage Digital Insulation Tester

Description

With the 380396 measure Insulation Resistance to 60GΩ with test voltages of 500V, 1000V, 2500V, and 5000V. Featuring polarization Index measurement (PI), Dielectric Absorption Ratio measurement (DAR), AC/DC Voltage measurement to 600V with Min/Max, Peak and Relative functions, and 1 to 15 minute timer function for IR measurements. Comes with test leads, eight C batteries, 220V AC adaptor, heavy duty carrying case, and user manual.

• Test Voltages of 500V, 1000V, 2500V, and 5000V
• Measure Insulation Resistance to 60GOhm
• Large 6000 count display with bargraph and backlight
• Polarization Index measurement (PI)
• Dielectric Absorption Ratio measurement (DAR)
• AC/DC Voltage measurement from 0 to 600V with Max/Min, Peak and Relative functions
• 1 to 15 minute timer function for IR measurements
• Resistance measurement
• Indication of output voltage and discharge voltage
• Auto-discharge function and voltage output warning function
• Autoranging, Auto Power off and battery check
• Complete with test leads, 8 x C batteries, 220V AC adaptor, and heavy duty carrying case
