GIACOMINI A61 Test and Drain Valve – DB-A61Y006-G

A61 Giacomini Test and Drain valve for sprinkler systems combines the functions of test and drain for wet sprinkler systems. A61 valves have forged brass body with chrome plated brass ball valve and PTFE seats. The valves complies with the requirements of NFPA-13, NFPA-13R and NFPA-13D. The A61 valves are single handle ball valves with three working positions. They include tamper resistant test orifice and sight glass for the visual control.

Test and drain valve for sprinkler systems combines the functions of test and drain for wet sprinkler systems. complies with the requirements of NFPA-13, NFPA-13R and NFPA-13D and is FM approved and UL listed.

Features

• Rp, EN 10226 threads 1? – 1 1/4? – 1 1/2? – 2?
• NPT threads 1? – 1 1/4? – 1 1/2? – 2?
• Groove connections 1 1/4? – 2?
• Forged brass body
• Chrome plated brass ball
• Steel handle
• PTFE seats.
• Indication disk in brass
• Sight glasses in polycarbonate
• Single handle ball valves with three working positions
• Tamper resistant test orifice and sight glass included
• Rated pressure: 300 psi
