Description
Specifications
| Application | Provides access to the interior of the raceway for wire pulling , splicing and maintenance, Allows connection of straight and branch conduit runs and 90 degree bends |
| Brand | Appleton™ |
| Capacity | 4.35 in³ |
| Catalog Number | LR50DCG |
| Connection Type | Threaded |
| Country of Origin | IN |
| Dimensions | 4.4 in L x 2.06 in W x 1.64 in H |
| Finish | Epoxy Powder Coated |
| Gross Weight Per Pack | 0.30000000 |
| Gross Weight UOM | lb |
| Height | 1.64 in |
| Hub Size | 1/2 in |
| Length | 4.4 in |
| Manufacturer | Appleton, Division of Emerson |
| Material | Die Cast Aluminum |
| Number of Hubs | 2 |
| Standard | UL Standard: 514A; UL Listed: E53330; CSA Standard: C22.2 No. 18.3; CSA Certified: 208044; NEMA: FB-1 |
| Standards | RoHS CompliantUL 514A File No. E53330CSA C22.2 No. 18.3 File No. 208044NEMA FB-1 |
| Sub Brand | NEER |
| Type | Type LR |
| UNSPSC | 39131708 |
| Width | 2.06 in |
