2.5″ GUAT PVC Coated; Crouse Hinds.

Description

Crouse Hinds GUA Style Fittings are available in a variety of shapes and dimensions. GUA style boxes are used in hazardous locations. All GUA style boxes are supplied PVC coated with PVC coated covers and a seal between the coating of the boxes and the coating of the covers.

Features

• GUA conduit boxes have:
  • Neoprene o-ring standard to meet NEMA 4 requirements
  • Cast ears on cover to permit easy removal and tightening
  • Internal green ground screw #8
  • Four standard mounting pads except for boxes with bottom hubs
  • Threaded cover openings
  • Ten different hub arrangements
  • Taper threaded hubs to provide grounding continuity
  • Smooth integral hub bushing protects conductor insulation when pulling
  • Surface covers furnished with boxes
  • Sealing covers, dome covers and fixture hanger covers are available
  • Cover threads are 12 pitch standard; 16 pitch on select aluminum shapes and

Standards

• National Electric Code: Class I, Division 1 & 2, Groups C, D, Class III
• UL Standard 886
• ANSI Standard C-33.27
• CSA Standard: C22.2 No. 30
• NEMA/EEMAC 3, 4
